- 您现在的位置：买卖IC网 > Sheet目录203 > APS3636VR (Tripp Lite)INVERTER 3600W 36VDC OR 120VAC
APSRM4)
APS3636VR serves as a truck/RV/Industrial or stationary DC-to-AC inverter with automatic line-to-battery
transfer and integrated battery charger
Supports 120V AC output from a 120V AC line power source or 36V DC battery source
3600 watts continuous AC output in inverter mode, 3600 watts continuous AC output in AC mode
Double Boost inverter output supports momentary startup loads up to 200% of the continuous rating for up to 10 seconds
3 stage, 30 amp battery charger with adjustable settings for wet/gel battery types offers fast, reliable battery recharging
Moisture-resistant construction enables vehicular or marine operation in high humidity environments
3 position operating mode switch supports "AUTO" mode to enable automatic transfer between DC and AC modes, CHARGE-ONLY to maintain a full
battery charge when AC is present without auto transfer and SYSTEM OFF settings
Set of six front panel LEDs display AC/DC operational modes, overload status, DC voltage level, shutdown status and system fault status
Set of 4 configuration dipswitches support wet/gel battery charging profiles, adjustable 135/145V high voltage auto transfer during overvoltages and
selectable 75/85/95/105V AC low voltage auto transfer during brownouts
Resettable 25A charger AC input breaker and resettable 30A AC output breaker and automatic 2 speed cooling fan protect the inverter from load and
temperature related failures
Grounding lug properly connects the inverter/charger system to earth ground or vehicle grounding system
Automatic overload and thermal shutoff safely turns off inverter as excessive loads or overheating conditions develop
Load sensing control dial enables adjustable load threshold required to automatically turn the inverter on and off in DC mode as load conditions change
Specifications
OVERVIEW
Intended Application
OUTPUT
Frequency compatibility
Output watts
Continuous output capacity (watts)
Peak output capacity (watts)
Output nominal voltage
Output voltage regulation
Output frequency regulation
Overload protection
Outlet quantity / type
INPUT
Nominal Input Voltage(s) Supported
Recommended Electrical Service
Industrial Back up Power, Alternative Emergency Power,(Sump Pumps, Lighting, Computers & Radio's)
60 Hz
3600
3600
7200
120V
LINE POWER (AC): Maintains 120V nominal sine wave output from line power source. INVERTER POWER (AC):
Maintains PWM sine wave output voltage of 120 V AC (+/-5%).
60 Hz (+/- 0.3 Hz)
Includes 25A input breaker dedicated to the charging system and 30A output breaker for AC output loads.
Hardwire
120V AC
DC INPUT: Requires 36VDC input source capable of delivering 114A for the required duration (when used at full
continuous capacity - DC requirements increase during Over-Power and Double-Boost operation).
2 / 4
